DanX CF – swimming pool air handling units

SKU: DanX CF
Enquire Now Brochure not available

Overview

The DanX CF is a very effective outdoor air dehumidification system with a highly efficient counter-flow heat exchanger. This system perfectly controls the humidity and indoor temperature while offerring significant running cost reductions due to real energy savings of up to 80%. The integrated mixing function ensures that only the exact quantity of outdoor air needed is supplied. This keeps running costs at a minimum.

Free cooling is also an option during summer, when the unit can add up to 100% outdoor air into the pool area through the integrated by-pass.

For countries with high outdoor summer temperatures the system can be equipped with an additional cooling coil for further dehumidification and air cooling.

A wide range of fan types, filter qualities and coils are is available on request, enabling you to create the perfect solution for your requirements.

Key features

  • User-friendly control system for high-quality demand management. Automatic monitoring and control of temperature and humidity of the pool hall
  • Counter-flow heat exchanger with a high efficiency of more than 90% and a low pressure drop
  • Built-in bypass for free cooling in the summertime
  • Highly energy-efficient EC plug fans
  • Efficient bag filters in different lengths and qualities with low pressure drops are available
  • Load-bearing frame construction module with hot-dip galvanised, powder-painted sandwich panels with 50mm mineral wool insulation, internal partition walls with 30mm and bottom frame with adjustable feet
  • Designed to withstand the aggressive swimming pool environment (corrosion class C4 according to EN/ISO 12944-2), with epoxy-coated counter-flow heat exchanger, heating coil with aluminium frame, prepainted fins and epoxy coating to protect all fasteners, bolts, nuts
  • Large inspection doors with strong hinges and tongue locks and handles for easy access for service
  • Modular unit for easy and quick installation – all sensors and electrical components pre-connected
  • BMS communication with either Modbus or BACnet

Suitable for

Products specifications

Attribute nameAttribute value
System unit
Nominal air volume(m³/h)3100
Outdoor air volume(%)0-100
Power supply(V/Hz)400/3ph/50
Weight(kg)800
Height(mm)1700
Width(mm)3790
Depth(mm)880
Capacity (30°C/80% RH)/Power consumption (l/24h/W)18/320
