Sorry - this product is no longer available

CDP 165 – swimming pool dehumidifiers

High capacity ducted swimming pool and commercial dehumidifiers
Enquire Now Brochure not available

Overview

The CDP 165 condensation dehumidifiers have been designed for ducted installation in your swimming pool plant room. Ideal for hotel pools, private pools and therapy pools, this dehumidifier range is renowned for its build quality and energy efficiency.

Mounting

  • CDP 165 can be placed on the floor using a shock-absorbing floor mount kit (accessory)
  • A water heating coil can be mounted in the air outlet duct for further heating of the dry air (accessory)

High-quality and energy-efficient swimming pool dehumidifiers for ducted installation in a plant room.

The CDP ducted range works in accordance with the condensation principle. A fan draws the humid air into the dehumidifier and through an evaporator coil. When passing through the evaporator the air is cooled down to below its dew point temperature, and its content of water vapour is condensed into water, which falls into the drip tray and then is led from the drip tray to a drain. The cold, dry air is then passed over the condenser coil where it is re-heated, before leaving the unit at a temperature, which is approx. 5°C higher than at the inlet.



Key features

  • The CDP 165 are built into a cabinet made of hot-galvanized, powder painted and double-skinned panels with 50mm insulation
  • Evaporator and condenser coils are protected against corrosion
  • The condensate outlet is located on the air inlet side
  • The outlet stub can be connected to a water hose
  • Air inlet through a filter placed in a removable frame
  • Dry air outlet positioned either horizontally (through the side) or vertically (through the top) of the unit
  • The access for inspection can be moved to the opposite side
  • Fresh air (15%) inlet possible through fresh air duct
  • Can be supplied with an optional water-cooled condenser
  • Rotary/reciprocating compressor
  • Radial fan



Suitable for

  • General industry and production
  • Leisure and recreation
  • Museum and gallery preservation
  • Prestige and classic car storage
  • Storage, preservation and archives
  • Swimming pools
  • Buildings and commercial sapces

Products specifications

Attribute nameAttribute value
System unit
Operating temperature range(°C)20-38
Operating humidity range(% RH)40-100
Dehumidification @ 28°C/60% RH(l/24h)162
Air flow (m³/h)3,600
Power supply(V/Hz)400/3ph/50
Sound level(dB(A))63
R407c gas weight/CO2 equivalent(kg/t)6.8/12.06
Water-cooled condenserOptional
Weight(kg)190
Product size (w x d x h) (mm)1400 x 1010 x 975
