AC 24 – tent cooler

SKU: AC 24
Enquire Now Brochure not available

Overview

The high performing AC 24 air-conditioning solution allows humanitarian organisations to procure and use the equipment for refugee camps, mobile hospitals and clinics at the right price point. It is strong, compact and operates on 1 phase 230V power supply. The mobile unit is easy to set up and operate with minimum amounts of maintenance and service required.

It is designed with multiple deployments in mind, meaning it can be used at one site, then dismounted, stored, and re-used at a new location with different climatic requirements. This is an important feature for humanitarian organisations operating with projects across different countries, regions and climate zones. From the deserts of North Africa and the Middle East to the mountains of South America, the jungles of South East Asia and the Arctic areas of Scandinavia this product provides the climatic solution your organisation needs.

Key features

  • The AC 24 is built into a cabinet manufactured from 0.9-2.5mm galvanized and powder coated steel sheet
  • Top finish painting is pure white, RAL 9010
  • Cooling at outside temperatures up to +55°C
  • Environmentally friendly R134a refrigerant
  • High/low pressure switch ensuring a long compressor lifespan
  • The unit connects to the mains power supply or to a separate diesel generator via a 10m power cable with a CEE plug
  • Temperature control carried out by a room thermostat hard-wired to the air-conditioner
  • Inlet and discharge openings for Ø315mm uninsulated, flexible ducts
  • Easy transportation by either forklift or on the four, mounted wheels (accessory)
  • Setup and operation can be done by a single person

Products specifications

Attribute nameAttribute value
System unit
Registered NSN numberyes
Operating temperature range, cooling(°C)+20 – +55
Air flow (m³/h)2,180
Sound level @ 1.5m(dB(A))62
Protection classIPX5
RefrigerantR134a
Nominal cooling capacity(KW)6.0
Power supply(V/Hz)230/1ph/50
Max. running current, cooling(A)14
Locked rotor amperage (LRA)(A)40
Hose connection(Ømm)1 x 315
Product size( l x w x h)(mm)1110 x 919 x 752
Weight(kg)160
